    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe

    Ask Lasest Price
    Brand Name : TISCO, BAOSTEEL
    Certification : ISO, SGS, BV
    Price : to be negotiated
    Supply Ability : 5000 Ton/Month
    Delivery Time : Within 7-15 workdays after receiving deposit or L/C
    • Product Details
    • Company Profile

    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe

    ASTM A106 Seamless Carbon Alloy Steel Pipe


    ASTM A106 Carbon Steel Pipe For High Temperature

    ASTM A106 / ASME SA106 pipes are seamless carbon steel pipes used for high tempertaure applications (up to 750 degrees F). These pipes are widely used in the oil & gas, petrochemical, power generation and ship-building industries (examples: refineries, downstream plants, vessels. boilers and towers). A106 pipes are particulary suited whenever the trasported fluid has either high temperature or high pressure (or both combined).


    ASTM A106 / SA106 pipes are available in size range from 1/2 to 28 inches, and in pipe schedules from 10 to 160. These pipes are supplied either in single random lenght (17-24') or double random lenght (36 -44').


    In terms of material grades, A106 pipes are manufactured in grade A, B and C. NPS 1-1/2? and below are available in the hot finished or by cold drawn type. Pipes of NPS 2 inch and above are generally are hot rolled manufatured. A106 pipes are produced out of killed steel. The chemical composition and Machanical Property of the three grades of ASTM A106 is shown in the following table:


    Chemical composition:

    Chemical composition, %
    ElementCMnPSSiCrCuMoNiV
    maxmaxmaxminmaxmaxmaxmaxmax
    A106 Grade A0.250.27-0.930.0350.0350.100.400.400.150.400.08
    A106 Grade B0.300.29-1.060.0350.0350.100.400.400.150.400.08
    A106 Grade C

    Product Name
    Carbon Steel Pipe
    Standard
    ASTM A106, ASTM A53, API 5L Gr.B, DIN17175,DIN1629
    Outer Dia:
    20mm-610mm
    Wall Thickness
    4mm-70mm
    Dia Tolerance
    Control with in the standard, OD:+-1%, WT:+-10%
    Materials
    10#,20#, 45#,16Mn,A106(B,C),A53(A,B),API J55,API K55,Q235,Q345,ST35.8,ST37,ST42,ST45,ST52
    Inspection
    ISO,BV,SGS,MTC
    Packing
    Waterproof paper, and steel strip packed. Standard Export Seaworthy Package.Suit forall kinds of transport,or as required
    MOQ
    5metric ton,sample order accepted
    Shipment time
    Within 7-10 workdays after receiving deposit

    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe


    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe


    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe

    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe

    Dia 20mm-610mm Seamless Carbon Steel Pipe MTC CS A106 Gr B Pipe
