Sj235jr S355jr Hot Rolled Mild Carbon Alloy Steel Plate Wear Resistant Steel Plate
S355jr - an useful structural grade steel with a minimum yield strength of 355 N/mm². S355 being widely used in the structural engineering and construction industries, S355 offers high yield and tensile strength and is supplied with a variety of treatments and test options to ensure that it is a highly usable steel in your various projects.
| Grade | Max C content for t in mm | Mn max | Si max | P max | S max | Cu max | N max | ||
| t ≤ 16 | >16 t ≤ | t >40 | |||||||
| S275JR | 0.21 | 0.21 | 0.22 | 1.5 | - | 0.035 | 0.035 | 0.55 | 0.012 |
| S355JR | 0.24 | 0.24 | 0.24 | 1.6 | 0.55 | 0.035 | 0.035 | 0.55 | 0.012 |
| S355JO | 0.20 | 0.20 | 0.22 | 1.6 | 0.55 | 0.035 | 0.035 | 0.55 | 0.012 |
| Grade | Yield (MPa)min | Tensile (MPa)min | Charpy V - notch longitudinal | |
| Strength at t = 16mm | Temp ( °C) | Energy (J) t =16mm | ||
| S275JR | 275 | 410/560 | 20 | 27 |
| S355JR | 355 | 470/630 | 20 | 27 |
| S355JO | 355 | 470/630 | 0 | 27 |
| Product Name | Carbon Steel Plate |
| Length | 4m-12m or as required |
| Width | 0.6m-3m or as required |
| Thickness | 0.1mm-300mm or as required |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled |
| Surface Treatment | Clean, blasting and painting according to customer requirement |
| Thickness tolerance | ±0.1mm |
| Material | Q345B,Q345C,Q345D,Q345E,Q390,Q390B,Q390C,Q390D,Q390E,Q420,Q420B,Q420C, Q420DQ420EQ460,Q460D,Q500C,Q500D,Q500E,Q550C, Q890C,Q890D16Mo3,16MnL,16MnR ,16Mng,16MnDRHG785D,S690QL,50MN |
| Application | It is mainly used to make structural parts such as car girder, beam, transmission shaft and car chassis parts, which can reduce the weight of the parts. |
| MOQ | 1tons.We also can accept sample order. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed. Standard Export Seaworthy Package.Suit for all kinds of transport,or as required |
| Capacity | 250,000 tons/year |
|
|
